Description

ACCESS POINT SPECIFICATIONS

• Frequency Bands: 2.4 GHz: 2.4 – 2.4835 GHz Channels 1 – 13 (ETSI/CE), Channels 1 – 11 (US) 5 GHz: 5.15 – 5.85 GHz
• SSID Security: WPA-2 (802.11i): WPA2-Enterprise (802.1x/EAP) & WPA2-Preshared-keys, Open
• Max SSIDs: 16
• Max Concurrent Clients: 512
• Max Data Rates: 2.4GHz: 400Mbps, 5GHz: 1733Mbps
• Ethernet Ports: Dual Gigabit Ethernet ports (2 x 10/100/1000Base-T)
• Antenna: Integrated Omni
• Antenna Gain: 8 dBi (2.4 GHz and 5 GHz)
• Power Consumed: Typical 18W. Max 24.6W
• Dimensions (cm): 315 x 215 x 66 mm (without bracket)
• Weight: 3.174 lbs (1700 gms) without bracket

WI-FI FEATURES

• Controller modes: Autonomous Controller-less operations (E.g.: roaming) • Cloud Managed
• On-premise virtualized controller
• Secure WLAN: WPA-TKIP, WPA2 AES, 802.1x 802.11w (Protected Management Frames)
• Hotspot 2.0: Passpoint supported; Captive Portal: cnMaestro Controller; Redirection to external RADIUS; Stand-alone AP based; Server DNS logging
• Authentication: RADIUS based 802.1x including EAP-SIM/AKA, EAP-PEAP, EAP-TTLS, and EAP-TLS; MAC auth (local database or External RADIUS server)
• Scheduled SSID: Turn SSID ON/OFF on a daily/weekly/time of day basis
• Guest Access: Yes. With Active Directory Integration; Vouchers; Rate limiting; Splash page creation on cnMaestro
