Specifications

Spectrum:

• Channel Spacing: Configurable on 5 MHz increments
• Frequency Range: Wide Band Operation 4910–5970 MHz
• Channel Width MHz: 5 | 10 | 20 | 40

Performance:

• ARQ: Yes
• Nominal Receive Sensitivity (w/FEC) @200MHz Channel: MCS0 -88 dBm; MCS7 = -70 dBm
• Nominal Receive Sensitivity (w/FEC) @40MHz Channel: MCS0 = -86 dBm; MCS7 = -68 dBm
• Modulation Levels (Adaptive): MCS0 (BPSK) to MCS7 (64QAM 5/6)
• Quality of Service: Three level priority (Voice, High, Low) with packet classification by DSCP, COS, VLAN ID, IP & MAC Address, Broadcast, Multicast and Station Priority
• Transmit Power Range: +3 to 28 dBm (combined, to regional EIRP limit) (1 dB interval)

Security:

• Encryption: 128-bit AES (CCMP mode)
